UNO-2271G-I331AE Edge IoT Gateway

Advantech, UNO-2271G-I331AE, Pocket Size Edge IoT Gateway, Intel A-m x7211RE dual core, 8 GB LPDDR5 onboard, 64 GB eMMC, 2 x 10/100/1000/2500BASE-T, 1 x USB 3.2 Gen 2, 1 x USB Type C (DP Alt mode), 1 x HDMI, 1 x M.2 B key, TPM 2.0, 10 - 30 VDC Power Input, IP30, CE, FCC, UL, CCC, BSMI, -20 - 60 deg. C.

UNO-2271G V3 Pocket-Size Edge IoT Gateway with Intel® Atom x7211RE

The UNO-2271G V3 is a pocket-size, fanless, cable-free edge IoT gateway from Advantech®'s UNO-2000 series. It is powered by an Intel® Atom dual-core x7211RE processor with 8 GB LPDDR5 onboard memory and 64 GB eMMC storage. The compact design provides 2 x 2.5G LAN, 1 x USB 3.2 Gen 2, 1 x USB Type-C (with DisplayPort Alt mode), and 1 x HDMI output. An optional M.2 B-key slot and second-stack extension kits enable additional COM ports, PoE, Wi-Fi, LTE/5G, and iDoor module expansion. The UNO-2271G V3 supports Windows 11 LTSC and Ubuntu 22.04/24.04.

Expansion and Connectivity

Optional second-stack kits include a 2 x COM / PoE PD / M.2 B-key configuration and a 2 x COM / M.2 B+E key configuration for LTE and Wi-Fi connectivity. An iDoor extension kit accepts M.2-based iDoor modules for additional Fieldbus and I/O expansion.

Features

• Intel® Atom dual-core x7211RE processor; 8 GB LPDDR5 onboard; 64 GB eMMC storage
• Operating temperature: -20~60°C with 0.7 m/s airflow
• 2 x 10/100/1000/2500BASE-T GbE LAN (Intel i226, RJ45)
• 1 x USB 3.2 Gen 2, 1 x USB Type-C (USB 3.2, DP Alt mode)
• 1 x HDMI (1920 x 1080 @ 60 Hz)
• Optional 1 x M.2 B+M key 2242 (SATA/PCIe) storage
• Pocket-size form factor: 100 x 70 x 41.5 mm
• Stand, wall, VESA, and DIN-rail mounting options
• TPM 2.0 hardware security; programmable watchdog timer
• Optional second-stack modules for COM ports, PoE PD, Wi-Fi, and LTE connectivity
• Power input 10~30 VDC; CE, FCC, UL, CCC, BSMI certified
• Supports Windows 11 LTSC, Ubuntu 22.04, Ubuntu 24.04
