UNO-2271G-E21BE Edge IoT Gateway

Advantech, UNO-2271G-E21BE, Pocket Size Edge IoT Gateway, Intel A-m E3815 single core 1.46 GHz, 4 GB DDR3L, 32 GB eMMC, 2 x GbE, 1 x USB 3.0, 1 x HDMI, 1 x full size mPCIe (mSATA shared), 10 - 30 VDC Power Input, IP30, CE, FCC, UL, CCC, BSMI, 0 - 50 deg. C.

UNO-2271G Intel® Atom™ Pocket-Size Smart Factory Edge Gateway with 2 x GbE, 1 x mPCIe, HDMI, eMMC

The UNO-2271G is a pocket-size fanless embedded PC from Advantech®'s UNO-2000 series. It is powered by an Intel® Atom™ E3815 single-core (1.46 GHz) or E3825 dual-core (1.33 GHz) processor with 4 GB DDR3L onboard memory and 32 GB eMMC storage. Three configuration options offer different I/O combinations including 2 x GbE, 1 x USB 3.0, 1 x HDMI, with optional 2 x RS-232/422/485 or 3 x USB 2.0. Its form factor matches a standard 2.5" SSD/HDD, and it supports Advantech®'s iDoor technology via second expansion stacks for additional Fieldbus, wireless, and I/O modules.

iDoor Expansion and Connectivity

The UNO-2271G supports more than 30 iDoor module combinations for smart factory applications. Optional second-stack expansion modules add 1 x iDoor slot, 2 x RS-232/422/485 ports, or 3 x USB 2.0 ports depending on configuration.

Features

• Intel® Atom™ E3815 single-core 1.46 GHz or E3825 dual-core 1.33 GHz; 4 GB DDR3L onboard; 32 GB eMMC storage
• Operating temperature: 0~50°C with 0.7 m/s airflow
• 2 x RJ45 10/100/1000 Mbps Ethernet
• 1 x HDMI (1920 x 1080 @ 60 Hz)
• 1 x USB 3.0; configuration-dependent additional 2 x RS-232/422/485 or 3 x USB 2.0
• 1 x full-size mPCIe slot for expansion
• Compact pocket-size form factor (100 x 70 x 30/60 mm), same dimensions as a standard 2.5" SSD/HDD
• Stand, wall, VESA, DIN-rail, and pole mounting options
• Supports 30+ iDoor modules for Fieldbus, wireless, and I/O expansion
• Power input 10~30 VDC; CE, FCC, UL, CCC, BSMI certified
• Supports Windows 7, Windows 10 LTSB, Advantech Linux
