SPC-618WE-PUD75A Explosion-Proof Panel PC
SPC-618WE-PUD75A Explosion-Proof Panel PC

Advantech

SPC-618WE-PUD75A Explosion-Proof Panel PC

Part #: SPC-618WE-PUD75A In Stock: Ready to Ship Contact for Availability Stock: Select Options for Details
$6,210.00
SPC-618WE-PUD75A
Weight:
15.00 LBS
pdf_1_name:
Spec Sheet
pdf_1_url:
pdfs/Advantech-SPC-618WE-Datasheet.pdf
hide_matrix:
True
in_stock:
False
sales_description:
Advantech, SPC-618WE-PUD75A, Explosion Proof Touch Panel Computer, 18.5 in FHD TFT LED LCD (1920 x 1080), PCAP Touch, Intel Core i7-1365URE deca core 1.7 GHz, 32 GB DDR5 4800, 256 GB Explosion Proof Certified SSD, 2 x 2.5GbE (Intel i226), 1 x DP 1.4a
sales_description_2:
, 1 x USB Type C (USB 3.2 Gen 2, DP 1.4a, 5V 3A max), 2 x USB 3.2 Gen 1 plus 2 x USB 2.0, 2 x RS232/422/485, TPM 2.0, 19 - 24 VDC Power Input, IP66 Rated Front Panel, IECEx and ATEX Zone 2/22, Class I Division i, BSMI, CCC, CE, FCC Class A, -20 - 60
sales_description_3:
deg. C.
parent_sku:
SPC-618WE-PUD75A
facet_certification:
Hazardous Location
facet_features:
Ethernet
facet_features:
X86
facet_mounting:
Panel
facet_temperature_range:
Extended
facet_temperature_range:
Standard
facet_type:
Panel PC With Monitor
Adding… The item has been added
Commonly Purchased with:
Dynics Industrial Panel-Mount PCs
Moxa MPC-2197Z Panel PC (Custom)
$4,099.00

Details

Advantech, SPC-618WE-PUD75A, Explosion Proof Touch Panel Computer, 18.5 in FHD TFT LED LCD (1920 x 1080), PCAP Touch, Intel Core i7-1365URE deca core 1.7 GHz, 32 GB DDR5 4800, 256 GB Explosion Proof Certified SSD, 2 x 2.5GbE (Intel i226), 1 x DP 1.4a, 1 x USB Type C (USB 3.2 Gen 2, DP 1.4a, 5V 3A max), 2 x USB 3.2 Gen 1 plus 2 x USB 2.0, 2 x RS232/422/485, TPM 2.0, 19 - 24 VDC Power Input, IP66 Rated Front Panel, IECEx and ATEX Zone 2/22, Class I Division i, BSMI, CCC, CE, FCC Class A, -20 - 60 deg. C.

SPC-618WE 18.5" FHD TFT LED LCD Touch Panel Computer with Intel® Raptor Lake-U Platform and IECEx/ATEX and Class I Division II Explosion-Proof Certification

The SPC-618WE is an explosion-proof touch panel computer from Advantech®, powered by the 13th Generation Intel® Core™ i7-1365URE deca-core processor. It features an 18.5" Full HD TFT LCD display with PCAP touch, 32 GB DDR5 memory, and an explosion-proof certified SSD. The fanless design and IP66-rated front panel make it suitable for hazardous environments, and it carries IECEx/ATEX Zone 2/22 and Class I Division II explosion-proof certifications. The system provides 2 x 2.5GbE LAN, 2 x USB 3.2, 1 x USB Type-C, and 2 x RS-232/422/485.

Explosion-Proof Design and Hazardous Environment Suitability

The SPC-618WE is designed for deployment in Zone 2/22 hazardous areas per IECEx/ATEX standards and Class I Division II per North American requirements. The aluminum alloy front bezel and chassis grounding, IP66 ingress protection, and explosion-proof certified storage components ensure safe operation in environments with flammable gases, vapors, or dusts.

Features

  • 13th Gen Intel® Core™ i7-1365URE 1.7 GHz deca-core processor; 32 GB DDR5 4800 SO-DIMM
  • 18.5" FHD TFT LED LCD; 1920 x 1080 resolution; 350 cd/m² luminance; 1000:1 contrast ratio; 50,000-hour backlight life
  • PCAP touchscreen with above 85% light transmission
  • Operating temperature: -20~60°C without airflow
  • 2 x 2.5GbE LAN (Intel® i226); fanless design
  • 2 x RS-232/422/485; 2 x USB 3.2 Gen 1, 1 x USB Type-C (USB 3.2 Gen 2, DP 1.4a, 5V/3A), 2 x USB 2.0
  • 1 x DisplayPort 1.4a video output
  • Explosion-proof certified M.2 2280 SSD (sTLC or TLC, 256 GB or 512 GB options)
  • IECEx/ATEX Zone 2/22 and Class I Division II explosion-proof certification
  • IP66-rated front panel; aluminum alloy front bezel and chassis
  • Panel mount installation; 479.3 x 300.3 x 80 mm
  • TPM 2.0 built-in; power input 19~24 VDC (±15%); BSMI, CCC, CE, FCC Class A certified
  • Supports Windows 11 LTSC, Ubuntu
