MOVE SpeedDome SD-540 Camera (5MP)

MOBOTIX MOVE SpeedDome SD-540-IR-VA 5MP 2720x1976, 4.3 to 170 mm Lens Focal Length, Servo Feedback, Wide Dynamic Range up to 130 dB, H.264, H.265, MJPEG (up to 4 Simultaneous Streams), Up to 40x Optical Zoom, PoE++ IEEE802.3bt, max. 51 W, AC24V max. 59.05 W / 87.12 VA Power Supply, IP66 and Full IK10, 40°C to 55°C

MOBOTIX MOVE SpeedDome SD-540 5MP IR

Supported by high-performance DNN processor/SoC in combination with state-of-the-art CMOS video sensor, the MOBOTIX MOVE 5MP IR Video Analytics Speed Dome is much more than just standard, providing crisp, noise-free and smooth video streaming at high 5MP resolution even under extreme low-light conditions. The integrated DNN-based video analytics functions include face and license plate recognition that can be combined with preset PTZ positions to enable a wide variety of 24/7 video surveillance applications.

The MOBOTIX EverClear superhydrophilic and self-cleaning nano coating of the front glass ensures best image quality even in rain and reduces cleaning efforts and operational costs.

High-Quality DNN Edge Video Analytics

The latest computer vision technology makes the DNN-accelerated video processing engine efficient at the edge. This integrated engine provides high accuracy, real-time object tracking, and 10 (DNN-based) video analytics functions including ALPR and human face recognition. Moreover, it allows simultaneous detection on multiple objects.

• Counting
• Intrusion
• Removed Objects
• Sabotage
• Face Recognition
• Abandoned Objects
• Stopped Vehicle
• Wrong Direction
• Loitering
• ALPR

EverClear Nano Coating

The new, groundbreaking MOBOTIX EverClear coating uses a special nano technology that transforms water droplets into an ultra-thin water film immediately upon impact. This ensures the highest image quality in rain and difficult environmental conditions and reduces maintenance costs due to its self-cleaning effect.

Features

• High light sensitivity: 0.02 Lux color, 0.001 Lux B/W
• 40x motorized zoom/focus lens 4.3 to 170 mm
• WDR up to 130 dB
• Integrated IR illumination up to 300 m/984 ft
• Quad streaming H.264/H.265/MJPEG
• Intelligent encoding, smart low-bitrate control
• MOBOTIX MxMessageSystem
• 2D & 3D motion-compensated noise reduction (MCTF)
• ONVIF Profile S/G/T/M support
• Electronic image stabilizer (EIS)
• Auto object tracking, DNN-based (persons, vehicles)
• DNN video analytics (8 VA, Face & ALPR) linkable to PTZ presets & smart event functions
• Smart Event Functions
• microSD/SDHC/SDXC card support up to 1 TB
• Dual power support (IEEE802.3bt/AC24V)
• Outdoor protection rate IP66, IK10 housing
• Temp. Range –40 to 55 °C/-40 to 131 °F with integrated heater ON
• EverClear coating of front glass
