EDS-408A-3S-SC-48 Series Switches
EDS-408A-3S-SC-48 Series Switches

Moxa

EDS-408A-3S-SC-48 Series Switches

Part #: EDS-408A-3S-SC-48 Series In Stock: Ready to Ship Contact for Availability Stock: Select Options for Details
from $2,217.24
EDS-408A-3S-SC-48 Series
Weight:
3.00 LBS
pdf_1_name:
Spec Sheet
pdf_1_url:
pdfs/EDS-408A-3S-SC-48_Series.pdf
hide_matrix:
False
sales_description:
EDS-408A-3S-SC-48 Series Series 8-Port Managed Industrial Ethernet Switches with 3 Fiber Ports, ±24 and ±48 VDC Power Inputs. (Please Specify Model Number.)
parent_sku:
EDS-408A-3S-SC-48 Series
pdf_2_name:
Quick Start Guide
pdf_2_url:
pdfs/EDS-408A-3S-SC-48_Series_QuickStart.pdf
facet_form_factor:
Fixed
facet_management:
Managed - Layer 2
facet_mounting:
DIN-Rail
facet_port_count:
7 to 12
facet_port_speed:
10/100
facet_port_types:
RJ45
facet_port_types:
SC
facet_port_types:
Singlemode
facet_power_considerations:
Low Voltage (Typically 12/24/48 VDC)
facet_temperature_range:
Extended
facet_temperature_range:
Standard
Adding… The item has been added
Commonly Purchased with:
DINSpace BRKT-19DR-5U-CM Rackmount DIN-Rail Adapter
$300.00
Moxa NDR-120-48 Power Supply
$129.70

Models

Product ID Description Price
EDS-408A-3S-SC-48 Moxa Entry-Level Managed Industrial Ethernet Switch with 5 x 10/100BaseT(X) Ports RJ45, 3 Singlemode 100BaseFX Ports, SC Connector, 48VDC, 0 to 60 deg. C. $2,217.24
EDS-408A-3S-SC-48-T Moxa Entry-Level Managed Industrial Ethernet Switch with 5 x 10/100BaseT(X) Ports RJ45, 3 Singlemode 100BaseFX Ports, SC Connector, 48VDC, -40 to 75 deg. C. $2,365.07

Details

EDS-408A-3S-SC-48 Series Series 8-Port Managed Industrial Ethernet Switches with 3 Fiber Ports, ±24 and ±48 VDC Power Inputs. (Please Specify Model Number.)

The EDS-408A-3S-SC-48 are 8-port managed Ethernet switches designed especially for industrial applications. The switches support a variety of useful management functions, such as Turbo Ring, Turbo Chain, ring coupling, port-based VLAN, QoS, RMON, bandwidth management, port mirroring, and warning by email or relay. The ready-to-use Turbo Ring can be set up easily using the web-based management interface, or with the DIP switches located on the top panel of the EDS-408A-3S-SC-48 switches.

Features & Benefits

  • IPv6 Ready logo awarded (IPv6 Logo Committee certified)
  • DHCP Option 82 for IP address assignment with different policies
  • Modbus/TCP industrial Ethernet protocol supported
  • Turbo Ring and Turbo Chain (recovery time < 20 ms at full load), and RSTP/STP (IEEE 802.1w/D)
  • IGMP snooping and GMRP for filtering multicast
  • Port-based VLAN, IEEE 802.1Q VLAN, and GVRP to ease network planning
  • QoS (IEEE 802.1p and TOS/DiffServ) to increase determinism
  • RMON for efficient network monitoring and proactive capability
  • SNMPv1/v2c/v3 for different levels of network management security
  • Bandwidth management to prevent unpredictable network status
  • Port mirroring for online debugging
  • 0 to 60°C operating temperature range (standard models)
  • -40 to 75°C operating temperature range (T models)

Documentation

Spec Sheet Quick Start Guide
