ADAM-6015-DE Analog I/O Module

Advantech, ADAM-6015, 7-Channel RTD Input Module, Pt 100/1000, Balco 500, and Ni 518 Support, 2 or 3 Wire RTD, Wire Burnout Detection, 2,000 VDC Isolation, 10/100Base T(X) Ethernet, Modbus TCP+TCP/IP, UDP, and RESTful, 10 - 30 VDC Power Input, UL, CE, FCC, C1D2, -10 - 70 deg. C.

ADAM-6015 7-Channel Isolated RTD Input Modbus TCP Module

The ADAM-6015 is a 7-channel isolated RTD input module from Advantech®'s ADAM-6000 series Ethernet I/O lineup. It supports Pt, Balco, and Ni RTD input types and communicates over Modbus/TCP, TCP/IP, and UDP protocols. The ADAM-6000 series is designed for remote monitoring and cross-site device management, enabling straightforward integration into SCADA systems, databases, and cloud platforms including Microsoft Azure.

Smart Control and Peer-to-Peer Connectivity

ADAM-6015 supports Peer-to-Peer (P2P) communication and Graphic Condition Logic (GCL), allowing standalone logic control and channel mapping between distributed I/O modules without additional controllers or programming. Configuration is handled through the Advantech IO Module Utility.

Industrial Ruggedness and Protection

The module features 2,000 VDC isolation protection, built-in TVS/ESD protection, and power reversal protection. It operates from -10 to 70°C in standard configuration and from -40 to 70°C in the D version, making it suitable for demanding industrial environments.

Features

• 7 differential analog input channels supporting Pt 100, Pt 1000, Balco 500, Ni 518 RTD types
• Supports both IEC 60751 ITS90 (0.00385 Ω/Ω/°C) and JIS C 1604 (0.00392 Ω/Ω/°C) standards
• 16-bit resolution with 10 samples/second sampling rate; high-speed mode at 1K samples/second
• Accuracy ±0.1% or better at 25°C (standard mode)
• Wire burnout detection
• CMR 90 dB and NMR 60 dB @ 50/60 Hz (standard mode)
• Modbus/TCP, TCP/IP, UDP, and RESTful protocol support; MQTT and SNMP available on D version
• Peer-to-Peer (P2P) and Graphic Condition Logic (GCL) support
• 2,000 VDC isolation protection with built-in TVS/ESD and power reversal protection
• 10/100Base-T(X) Ethernet with 1 x RJ-45 connector
• Power input 10~30 VDC; operating temperature -10~70°C (-40~70°C for D version)
• Class I, Division 2, Groups A, B, C, and D hazardous location certification
• CE, FCC, UL certified
