Optical Cable Corporation

ECRA4211UA0 RJ45 Connector

Part #: ECRA4211UA0 In Stock: Ready to Ship Contact for Availability Stock: Select Options for Details
$92.35
ECRA4211UA0
Weight:
0.25 LBS
pdf_1_name:
Spec Sheet
pdf_1_url:
pdfs/OCC-RJack.pdf
hide_matrix:
True
in_stock:
False
sales_description:
Optical Cable Corporation R-Jack Industrial RJ45 Connector, CAT 5e, Includes Male Plug, Dust Cap and Straight Backshell, Black Anodized Metal Housing.
parent_sku:
ECRA4211UA0
pdf_2_name:
Brochure
pdf_2_url:
pdfs/ECRA4211UA0_Brochure.pdf
facet_application:
Ethernet
facet_gender:
Male
facet_material:
Metal
facet_style:
CAT 5e
facet_type:
RJ45
Adding… The item has been added

Details

Optical Cable Corporation R-Jack Industrial RJ45 Connector, CAT 5e, Includes Male Plug, Dust Cap and Straight Backshell, Black Anodized Metal Housing.

R-JACK Ethernet Interconnect Solution

In today's world of high-speed communications, Ethernet has become the platform for all voice, video and data services. R-JACK Ethernet Interconnect Solution, OCC's ruggedized family of RJ-45 receptacles, plugs, back shells and accessories, empowers customers to extend Ethernet platforms into harsh military and industrial operating environments.

The R-JACK Ethernet Interconnect Solution provides an efficient, comprehensive and affordable solution to Ethernet connectivity in harsh and environmentally challenged applications. R-JACK Ethernet components feature a smaller mechanical footprint (receptacles, dust caps, backshells), occupying less panel space, allowing higher density. R-JACK Ethernet receptacles feature 100% transversely sealed (IP-68) configurations as a standard product design, preventing dust, water or moisture penetration, with or without dust cap or plug engagement. R-JACK Ethernet receptacles offer comprehensive shielding and grounding effectiveness capable of sustaining higher data transmission rates as well as Electro-Magnetic Conductance (EMC) for military applications. Lastly, R-JACK Ethernet components feature multiple pre-kitted solutions including gaskets, O-rings, mounting brackets, and hardware, making it easier for customers to procure, install and integrate these components.

Applications

  • DATA, VOIP, IPTV in Harsh Environments
  • Railways
  • Radar Systems
  • Industrial Process Control
  • Data Acquisition and Control
  • Shelters
  • Battlefield Communication Systems
  • 10/100/1000 Base-T

Features and Benefits

  • Conforms to MIL-DTL-83723 and MIL-DTL-38999 mechanical specifications:
    • Smaller profile affords tighter panel density with ample space to remove dust cap, unlike other MIL-DTL38999 style products
  • MIL-DTL-38999 form-fits receptacles available:
    • Both MIL-DTL-38999 equivalent jam-nut and flange receptacle versions are available and feature smaller dust cap profiles
  • Transversely sealed, standard feature for jam-nut, flange-mount and in-line receptacles:
    • Meets/exceeds ip-68 rating with or without dust covers engaged or when plug is engaged with receptacle
  • Common cable strain relief back shell with conductive compressive fittings for shielded cable
    • Designed to integrat with jam-nut, flange-mount, in-line receptacles and plugs
    • Compression nut establishes 10 lb cable strain relief
    • Internal conductive compression developed inter-operate with cable braid to form 360 degree ground plane
  • Pre-provisioned mounting hardware, conductive o-rings, gasket options
    • Mounting hardware options for flange-mount units include:
    • No mounting hardware
    • Screws with "pressed in" pem nuts
    • Screws with nylon "locking" nuts
    • Screws with mounting bracket
    • Self sealing screws for "sealed" flange-mount options
    • Nitrile or conductive o-ring, gaskets supplied as standard provision
