ioLogik E2210 I/O Server

Moxa

ioLogik E2210 I/O Server

Part #: ioLogik E2210 In Stock: Ready to Ship Contact for Availability Stock: Select Options for Details
$378.14
ioLogik E2210
pdf_1_name:
Spec Sheet
pdf_1_url:
pdfs/ioLogik_E2210.pdf
hide_matrix:
True
in_stock:
True
sales_description:
Moxa Active Ethernet I/O Server, 24Vdc 12DI + 8DO, I/O control via Modbus/TCP and SNMP, Active I/O Messaging via TCP/UDP/email/SNMP tag.
parent_sku:
ioLogik E2210
facet_form_factor:
Modular
facet_input_output_count:
16+
facet_input_output_type:
Digital Only
facet_mounting:
DIN-Rail
facet_temperature_range:
Standard
Adding… The item has been added
Commonly Purchased with:
Moxa ioLogik E2212 I/O Server
$510.31
Moxa ioLogik E2214 I/O Server
$576.26

Details

Moxa Active Ethernet I/O Server, 24Vdc 12DI + 8DO, I/O control via Modbus/TCP and SNMP, Active I/O Messaging via TCP/UDP/email/SNMP tag.

Simple Applications without Programming
The ioLogik E2210 can convert a trigger event result directly into a digital alarm output. This can be set up using the ioAdmin UI to define an IF-THEN-ELSE Logic rule, eliminating the need to write programs for PCs or controllers.

Software Event Counter Input and Pulse Output
Each digital input can be independently configured for DI or Event Counter mode, and output can be independently configured for DO or Pulse Output mode.

Features & Benefits

  • Instant event messaging by TCP/UDP/email/SNMP-trap
  • Easy-to-use Click&Go™ Logic for local output control
  • 12-point 24 VDC digital input with counter
  • 8-point 24 VDC digital output with pulse output
  • PC-based configuration utility and web console
  • I/O control over Modbus/TCP and SNMP protocol
  • Windows/WinCE VB/VC.NET and Linux C APIs
  • Peer-to-Peer I/O without controller

Documentation

Spec Sheet
