SDI Series Switches

Westermo

SDI Series Switches

Part #: SDI Series In Stock: Ready to Ship Contact for Availability Stock: Select Options for Details
from $375.00
SDI Series
pdf_1_name:
SDI-541 Specs
pdf_1_url:
pdfs/westermo-sdi-541-switch.pdf
pdf_2_name:
SDI-550 Specs
pdf_2_url:
pdfs/westermo-sdi-550-switch.pdf
pdf_3_name:
SDI-862 Specs
pdf_3_url:
pdfs/westermo-sdi-862-switch.pdf
pdf_4_name:
SDI-880 Specs
pdf_4_url:
pdfs/westermo-sdi-880-switch.pdf
hide_matrix:
False
sales_description:
Westermo SDI Series Unmanaged Industrial Ethernet Switches. (Please Specify Model.)
parent_sku:
SDI Series
facet_form_factor:
Fixed
facet_management:
Unmanaged
facet_mounting:
DIN-Rail
facet_port_count:
7 to 12
facet_port_speed:
10/100
facet_port_types:
Copper Only
facet_port_types:
Multimode
facet_port_types:
SC
facet_port_types:
Singlemode
facet_power_considerations:
Low Voltage (Typically 12/24/48 VDC)
facet_temperature_range:
Extended
facet_temperature_range:
Standard
Adding… The item has been added
Commonly Purchased with:
DINSpace BRKT-19DR-4U Rackmount DIN-Rail Adapter
$236.00
Fiber Optic Patch Cables
$17.90
See Options

Models

Product ID Description Price
SDI-862-MM-SC2 Westermo SDI Series Unmanaged Industrial Ethernet Switch, 6 x 10/100Base-TX RJ45 Copper Ports, 2 x 100Base-FX Multimode SC Fiber Ports (2Km), Redundant 10-60 VDC Power Inputs, DIN-Rail Mount, IP31 Aluminum Housing, -10 to +70 deg C. (Article #3625-0110) $730.00
SDI-862-SM-SC30 Westermo SDI Series Unmanaged Industrial Ethernet Switch, 6 x 10/100Base-TX RJ45 Copper Ports, 2 x 100Base-FX Singlemode SC Fiber Ports (30Km), Redundant 10-60 VDC Power Inputs, DIN-Rail Mount, IP31 Aluminum Housing, -10 to +70 deg C. (Article #3625-0120) $949.00
SDI-880 Westermo SDI Series Unmanaged Industrial Ethernet Switch, 8 x 10/100Base-TX RJ45 Copper Ports, Redundant 10-60 VDC Power Inputs, DIN-Rail Mount, IP31 Aluminum Housing, -25 to +70 deg C. (Article #3625-0100) $375.00

Details

Westermo SDI Series Unmanaged Industrial Ethernet Switches. (Please Specify Model.)

A high speed switch core ensures full speed on all ports and transparency to any Ethernet protocol.

The unit is designed for DIN rail mounting into industrial cabinets allowing simple Ethernet connections to be established between PLCs, I/O units, drives, inverters and HMIs.

The SDI series is easy to use, simply connect power to the screw terminals and plug in your RJ-45 cables. If you plan to use the fault contacts a DIP switch allows configuration whilst LEDs provide simple diagnostics if required. A broadcast storm filter helps out if a loop is created by mistake.

Features and Benefits

  • Basic automation connectivity solution
    • Up to 8-ports 10/100 TX and Base-FX fiber ports
    • Compact Fast Ethernet Switch
    • 3.2Gbit/s Switch Fabric with excellent data exchange performance
  • Designed for easy industrial installation
    • DIN rail mount
    • Variable power input, AC 18 – 27 V / DC 18 – 32 V
    • Fault relay alarm
  • Operation within industrial environments
    • Aluminum case with IP-31 grade protection
    • -10 ~ 60 deg. C operating temperature
  • Easy configuration and use
    • DIP switch fault contact configuration
    • No user set up required
    • Broadcast storm filter

Documentation

SDI-541 Specs SDI-550 Specs SDI-862 Specs SDI-880 Specs
