Rittal 316 Stainless Steel Wallmount Enclosures

Rittal

Rittal 316 Stainless Steel Wallmount Enclosures

Part #: Rittal 316 Stainless Steel Wallmount Enclosures In Stock: Ready to Ship Contact for Availability Stock: Select Options for Details
from $525.34
Rittal 316 Stainless Steel Wallmount Enclosures
pdf_1_name:
Spec Sheet
pdf_1_url:
pdfs/Rittal-Wallmount-Enclosures.pdf
hide_matrix:
False
sales_description:
Rittal Type 316 Stainless Steel Wallmount Enclosure, NEMA 4X, Includes Back Panel. (Please Specify Size.)
parent_sku:
Rittal 316 Stainless Steel Wallmount Enclosures
facet_application:
Indoor
facet_application:
Outdoor
facet_material:
Stainless Steel
facet_mounting:
Wall
facet_rating:
NEMA 4X
Adding… The item has been added
Commonly Purchased with:
Rittal 2433.500 Wallmount Bracket
$100.50
Rittal 8018.791 Wall Mount Brackets
$77.63

Models

Product ID Description Price
8018.525 Rittal WM121206N6 Wallmount Enclosure, NEMA 4X, 12x12x6 Inch (HxWxD), Hinged Door with 1 x Quarter-Turn Latch, Type 316 Stainless Steel. Includes WMMP1212 Back Panel. $525.34
8017.636 Rittal WM161206N6 Wallmount Enclosure, NEMA 4X, 16x12x6 Inch (HxWxD), Hinged Door with 1 x Quarter-Turn Latch, Type 316 Stainless Steel. Includes WMMP1612 Back Panel. $570.59
8017.644 Rittal WM161208N6 Wallmount Enclosure, NEMA 4X, 16x12x8 Inch (HxWxD), Hinged Door with 1 x Quarter-Turn Latch, Type 316 Stainless Steel. Includes WMMP1612 Back Panel. $604.04
8017.638 Rittal WM161606N6 Wallmount Enclosure, NEMA 4X, 16x16x6 Inch (HxWxD), Hinged Door with 1 x Quarter-Turn Latch, Type 316 Stainless Steel. Includes WMMP1616 Back Panel. $624.76
8017.628 Rittal WM201608N6 Wallmount Enclosure, NEMA 4X, 20x16x8 Inch (HxWxD), Hinged Door with 2 x Quarter-Turn Latch, Type 316 Stainless Steel. Includes WMMP2016 Back Panel. $730.62
8017.624 Rittal WM202008N6 Wallmount Enclosure, NEMA 4X, 20x20x8 Inch (HxWxD), Hinged Door with 2 x Quarter-Turn Latch, Type 316 Stainless Steel. Includes WMMP2020 Back Panel. $798.46
8017.632 Rittal WM242008N6 Wallmount Enclosure, NEMA 4X, 24x20x8 Inch (HxWxD), Hinged Door with 2 x Quarter-Turn Latch, Type 316 Stainless Steel. Includes WMMP2420 Back Panel. $884.47
8018.534 Rittal WM242010N6 Wallmount Enclosure, NEMA 4X, 24x20x10 Inch (HxWxD), Hinged Door with 2 x Quarter-Turn Latch, Type 316 Stainless Steel. Includes WMMP2420 Back Panel. $947.29
8017.623 Rittal WM242408N6 Wallmount Enclosure, NEMA 4X, 24x24x8 Inch (HxWxD), Hinged Door with 2 x Quarter-Turn Latch, Type 316 Stainless Steel. Includes WMMP2424 Back Panel. $974.71
8017.627 Rittal WM242412N6 Wallmount Enclosure, NEMA 4X, 24x24x12 Inch (HxWxD), Hinged Door with 2 x Quarter-Turn Latch, Type 316 Stainless Steel. Includes WMMP2424 Back Panel. $1,117.44
8017.637 Rittal WM302412N6 Wallmount Enclosure, NEMA 4X, 30x24x12 Inch (HxWxD), Hinged Door with 2 x Quarter-Turn Latch, Type 316 Stainless Steel. Includes WMMP3024 Back Panel. $1,271.03
8018.904 Rittal WM303010N6 Wallmount Enclosure, NEMA 4X, 30x30x10 Inch (HxWxD), Hinged Door with 2 x Quarter-Turn Latch, Type 316 Stainless Steel. Includes WMMP3030 Back Panel. $1,381.66
8017.629 Rittal WM363612N6 Wallmount Enclosure, NEMA 4X, 36x36x12 Inch (HxWxD), Hinged Door with 3-Point Latching L-Handle, Type 316 Stainless Steel. Includes WMMP3636 Back Panel. $1,930.51
8017.626 Rittal WM483612N6 Wallmount Enclosure, NEMA 4X, 48x36x12 Inch (HxWxD), Hinged Door with 3-Point Latching L-Handle, Type 316 Stainless Steel. Includes WMMP4836 Back Panel. $2,283.43
8017.631 Rittal WM603612N6 Wallmount Enclosure, NEMA 4X, 60x36x12 Inch (HxWxD), Hinged Door with 3-Point Latching L-Handle, Type 316 Stainless Steel. Includes WMMP6036 Back Panel. $2,721.75

Details

Rittal Type 316 Stainless Steel Wallmount Enclosure, NEMA 4X, Includes Back Panel. (Please Specify Size.)

Please Note: Enclosures may require being shipped on a pallet, which may incur additional shipping charges than those calculated using the shipping methods offered within the cart at check-out.  INS will contact the customer for authorization prior to shipment in these cases.

Rittal WM enclosures set the standard for maximum use of space and ease of installation. WM compact enclosures can be used for virtually any application. NEMA protection ratings are ensured through a secure locking system, foamed-in-place gasket and knife-edge perimeter. Features include a body constructed of cold rolled steel, steel doors and zinc-plated mounting panels. WM enclosures are readily available in all of the most popular sizes, protection categories and configurations – including universal disconnect cutout.

Features & Benefits

  • One-piece welded cold-rolled steel body
  • Stainless steel
  • Zinc-plated mounting panel standard
  • Available with universal disconnect cutout
  • Foamed-in-place gasket
  • Quick-release hidden 130° door hinges
  • Flange-trough collar opening channels liquids and dust away from enclosure gasket and enclosure interior
  • Left-hand hinged door (the single door configuration is reversible)
  • Wall-mounting holes
  • Single door enclosures less than 20” in height have one ¼ turn latch with screwdriver insert
  • Single door enclosures 20 - 40” in height have two ¼-turn latches with screwdriver inserts
  • Single door enclosures greater than or equal to 42” in height have a 3-point latching L-handle
  • Double door and disconnect enclosures have a 2- or 3-point latching L-handle
