PSI-010-FT2G-P8G Rail Switch

Westermo Unmanaged Industrial Gigabit 8-Port IEEE 802.3af/at PoE/PoE+ Booster Switch, 8 x 10/100/1000Base-TX RJ45 Copper PoE Ports, 2 x Copper/Fiber FE/GE Combo Ports, 12-48 VDC Power Input, DIN-Rail Mount, IP40 Metal Housing, -40 to +75 deg C. (Article #3626-0130)

The PSI-010-FT2G-P8G is a high-performance industrial unmanaged Power over Ethernet switch. It combines the plug-and-play nature of an unmanaged device with the capability to supply power to  high-power devices over long distances. With 8 copper ports providing up to 30 W PoE power output per port and a total power budget of 240 W, the possibilities for lean and simple installations are vast. Only one cable is required for both connectivity and power.

The switch can be connected to a larger network either by copper Gb-Ethernet or by fiber optic transceivers (SFPs). This offers flexibility for installations to reach both short and long distances by using  any of the many SFPs in the Westermo portfolio. In addition, it also offers a cost-effective connection with the copper port. A fiber optic connection can be made outside the premises, as there is no  electrical connection, allowing for diverse ground potentials.

Designed for harsh industrial environments, the switch is able to withstand extreme temperatures, vibrations, humidity, and electrical environments. The use of only industrial grade components  contributes to ensure market leading mean time between failure (MTBF), maximized service life and reduced operational and life cycle costs.

The device is thoroughly tested by external test institutes to meet a rich selection of EMC, isolation, vibration and shock standards. These standards are all to the highest levels suitable for industrial environments and rail trackside applications.

Features and Benefits

• Powerful Industrial Power over Ethernet (PoE) switch
  • Reduce complexity, one cable for power and connectivity
  • All 8 copper ports supporting up to 30 W, 802.3at (PoE+)
  • Total PoE power budget up to 240 W
• Flexible long distance / uplink connections
  • 2 pcs of fiber/copper combo ports
  • Choose either to use SFP or copper
• Robust for long service life
  • -40 to +75 deg. C operating temperature
  • Industrial and trackside type tested
  • Robust IP40 metal housing
