IMC-21GA Series Media Converters

Moxa

IMC-21GA Series Media Converters

Part #: IMC-21GA Series In Stock: Ready to Ship Contact for Availability Stock: Select Options for Details
from $262.52
IMC-21GA Series
pdf_1_name:
Spec Sheet
pdf_1_url:
pdfs/IMC-21GA_Series.pdf
hide_matrix:
False
sales_description:
Moxa IMC-21GA Series Industrial Gigabit Copper-to-Fiber Ethernet Media Converters. (Please Specify Model Number.)
parent_sku:
IMC-21GA Series
facet_form_factor:
Fixed
facet_port_speed:
10/100/1000
facet_port_types:
Copper
facet_port_types:
Multimode
facet_port_types:
SFP Fiber
facet_port_types:
Singlemode
facet_temperature_range:
Extended
facet_temperature_range:
Standard
facet_type:
Ethernet to Fiber
Adding… The item has been added
Commonly Purchased with:
DINSpace BRKT-19DR-5U-CM Rackmount DIN-Rail Adapter
$300.00
RJ45 CAT 5e Patch Cable - Unshielded
$3.15
See Options

Models

Product ID Description Price
IMC-21GA-LX-SC Moxa Industrial Gigabit Media Converter, 10/100/1000Base-T(X) to 1000Base-LX Singlemode w/ SC Connector (0-10km @ 9/125), Redundant 12-48 VDC Power Inputs, DIN-Rail Mount, -10 to +60 deg C. $531.70
IMC-21GA-LX-SC-T Moxa Industrial Gigabit Media Converter, 10/100/1000Base-T(X) to 1000Base-LX Singlemode w/ SC Connector (0-10km @ 9/125), Redundant 12-48 VDC Power Inputs, DIN-Rail Mount, -40 to +75 deg C. $666.13
IMC-21GA-SX-SC-T Moxa Industrial Gigabit Media Converter, 10/100/1000Base-T(X) to 1000Base-SX Multimode w/ SC Connector (0-500m @ 50/125), Redundant 12-48 VDC Power Inputs, DIN-Rail Mount, -40 to +75 deg C. $477.92
IMC-21GA Moxa Industrial Gigabit Media Converter, 10/100/1000Base-T(X) to 100/1000Base-SFP, Redundant 12-48 VDC Power Inputs, DIN-Rail Mount, -10 to +60 deg C. (SFP Modules Sold Separately) $262.52
IMC-21GA-SX-SC Moxa Industrial Gigabit Media Converter, 10/100/1000Base-T(X) to 1000Base-SX Multimode w/SC Connector (0-500m @ 50/125), Redundant 12-48 VDC Power Inputs, DIN-Rail Mount, -10 to +60 deg C. $370.07
IMC-21GA-T Moxa Industrial Gigabit Media Converter, 10/100/1000Base-T(X) to 100/1000Base-SFP, Redundant 12-48 VDC Power Inputs, DIN-Rail Mount, -40 to +75 deg C. (SFP Modules Sold Separately) $329.89

Details

Moxa IMC-21GA Series Industrial Gigabit Copper-to-Fiber Ethernet Media Converters. (Please Specify Model Number.)

Industrial Gigabit Ethernet-to-fiber media converters
The IMC-21GA industrial Gigabit media converters are designed to provide reliable and stable 10/100/1000BaseT(X) to 1000Base-SX/LX (SC) or 10/100/1000BaseT(X) to 100Base-FX or 1000Base-SX/LX (SFP-based) media conversion. The IMC-21GA supports IEEE 802.3az (Energy Efficient Ethernet) and 10K jumbo frames, allowing them to save power and enhance transmission performance. The converters come with a relay output warning alarm to help prevent damage and loss, and all IMC 21GA models are subjected to a 100% burn-in test, and are available in models that support a standard operating temperature range of 0 to 60 deg. C, and an extended operating temperature range of -40 to 75 deg. C.

Features & Benefits

  • Supports 1000Base-SX/LX with SC connector, or 100Base-FX or 1000Base-SX/LX with SFP slot
  • Link Fault Pass-through (LFP)
  • 10K jumbo frame
  • Redundant power input
  • Supports Energy Efficient Ethernet (IEEE 802.3az)
  • -10 to 60 deg. C standard operating temperature range
  • -40 to 75 deg. C operating temperature range (T models)

Documentation

Spec Sheet
