GP-IN2850 Reef Sharkee Multifunction 4x4 MiMo Antenna

Panorama Antennas, GP-IN2850, 7-in-1 Reef Sharkee Antenna (4 x 4 MIMO 4G/5G LTE plus 2 x 2 MIMO Wi-Fi plus GPS/GNSS), 698-7125 MHz, Panel/Threaded Bolt Mount, SMA-Male and RP-SMA-Male Connectors, 5 Meter Cable, Black.

GPSD[X]4-7-49[X] | 4x4 MiMo Reef Sharkee® Antenna

The GPSD[X]4-7-49[X] MiMo Reef Sharkee® antenna is designed to be a discrete one size fits all solution for mobile applications. The robust low profile housing contains 4x 4G LTE / 5G NR elements covering 698-960/1427-4900MHz. Versions of the product also contain up to 4x optional WiFi elements supporting WiFi 6e 2.4/5.150-7.125GHz and optional L1 only or L1/L5 GPS/GNSS module.
The whip position allows the use of a single, dual or tri-band whip operating across the VHF, UHF and 7/800MHz bands. The sleek sharkfin design has low visual impact and at only 52mm (2³) high the antenna can comply with certain state laws regarding light-bar obscuration on police vehicles.

The product is supplied with low loss flame retardant pigtail cables approved to UN ECE R118 and a variety of extension cables are available for different applications. The GPSD[X]4-7-49[X] can be installed on conductive or non-conductive panels but installations with a whip require a conductive ground plane.

Features and Benefits

• Sleek sharkfin design
• 4x4 MiMo 698-960/1427-4900MHz
• Up to 4x4 MiMo WiFi 6e (optional)
• GPS/GNSS L1/L5 or L1 only 30dB / 26dB LNA (optional)
• Whip position for single, dual or tri-band whips for secure comms
