GP-IN2768 Multifunction Sharkfin Antenna

Panorama Antennas, GP-IN2768, 3-in-1 Dual Sharkee Antenna (2 x 2 MIMO 4G/5G LTE plus Wi-Fi plus GPS), 698-5850 MHz, Panel/Threaded Bolt Mount, TNC Connectors, 5 Meter Cable, Black.

GPSB5G | Sharkee® | Multi-function Sharkfin Antenna

The GPSB5G Sharkee® provides antenna coverage for multiple technologies within one antenna housing. The GPSB range is trusted by public safety, utilities and transportation companies all over the world and the GPSB5G upgrades the range with an improved GPS/GNSS module with advanced filtering and 4G/5G coverage.

The GPSB5G offers three internal antenna systems, GPS/GNSS, 4G/5G cellular (698-960/1710-3800MHz), dual band WiFi (2.4/5.0GHz) and an optional whip mounting for VHF or UHF whips.

Requiring only a single hole fixing, the GPSB5G reduces vehicle damage, cost of installation and visual impact whilst protecting vehicle resale value.

The GPSB5G is suitable for the public safety (covert and discreet), industrial and transportation sectors, where a cost effective, efficient and robust antenna is essential to the application. Fitted with flame retardant pigtail cables compliant to UNECE R118 the GPSB5G is suitable for fitment to M3 category vehicles.

Features and Benefits

• OEM Sharkfin styling
• GPS/GNSS, 4G/5G and dual band WiFi in one housing
• Active GPS/GNSS antenna 26dB LNA
• Optional VHF or UHF Whip
