ALIF101T-DVI KVM Dongle Extender
ALIF101T-DVI KVM Dongle Extender

Adder

ALIF101T-DVI KVM Dongle Extender

Part #: ALIF101T-DVI In Stock: Ready to Ship Contact for Availability Stock: Select Options for Details
$1,084.00
ALIF101T-DVI
pdf_1_name:
Spec Sheet
pdf_1_url:
pdfs/AdderLink-ALIF101T-DVI.pdf
pdf_2_name:
User Manual
pdf_2_url:
pdfs/AdderLink-ALIF101T-DVI-Manual.pdf
hide_matrix:
True
in_stock:
False
sales_description:
AdderLink INFINITY 101T Compact Single-Monitor Network DVI Dongle Extender Transmitter, DVI and USB Extension Over Gigabit Ethernet, Copper (RJ45), Resolutions Up To 1920x1200.
parent_sku:
ALIF101T-DVI
facet_displays_supported:
1 Monitor
facet_kvm_extension_type:
Copper
facet_mounting:
Desktop
facet_type:
Network-Based KVM Extender
facet_video_type:
DisplayPort (DP)
Adding… The item has been added
Commonly Purchased with:
Belden 2412 0061000 Copper Cable - 1000FT
$368.70
Adder ALIF1002R-US Network DVI Receiver
$1,606.00

Details

AdderLink INFINITY 101T Compact Single-Monitor Network DVI Dongle Extender Transmitter, DVI and USB Extension Over Gigabit Ethernet, Copper (RJ45), Resolutions Up To 1920x1200.

ADDERLink™ INFINITY 101T (ALIF101T) is a high performance ZeroU™ IP KVM (Keyboard, Video, Mouse) dongle extender with matrix capability that enables the use of standard IT infrastructure to extend computers away from the user environment.

Features

  • ZeroU™ size
    The ADDERLink™ INFINITY 101T (ALIF101T) takes ZeroU™ of rack space in the server room allowing for ultimate flexibility and ease of installation.
  • IP-based
    Use your existing networking infrastructure to extend or matrix your computing resources to your users.
  • USB powered
    The device can be powered from USB. This means there is no need to provision for an external PSU. Options for powering from an external PSU or redundant PSU are also available.
  • Low power consumption
    Requires less than 3 watts.
  • Video options
    The system supports resolutions up to 1920 x 1200 @60Hz through a DVI interface
  • USB2.0
    Enables you to connect any USB HID (human interface device) from mouse and keyboards through to graphics tablets, jog shuttles, joysticks and 3D explorers. Supports high speed devices such as USB hard drives.
  • Seamless integration with the ADDERLink™ INFINITY range
    The ALIF101T can integrate seamlessly into your existing ADDERLink™ INFINITY setup, replacing or working in conjunction with your existing ALIF endpoints. (Refer to manual on AIM firmware requirements for a matrix installation)
  • Perfect digital video
    The ALIF101T uses an encoding system that is spatially-lossless, with 1:1 pixel mapping, so the digital video you receive is the same as the digital video leaving the remote computer ensuring the very best picture available and color accuracy.
  • Digital audio
    The system can deliver USB stereo audio (bi-directional) or embedded video standard stereo audio (uni-directional).
  • EDID management
    The system has intelligent EDID management to either allow the true characteristics of the monitor to be passed back to the computer, or controlled resolutions to be imposed.
  • Digital KVM matrix
    Using the ADDERLink™ INFINITY Manager (AIM) you can turn multiple point-to-point extenders into a matrix system that allows any workstation to connect to any computer connected to the network.

Documentation

Spec Sheet User Manual
