AA175.5 Power Supply

ESTeem

AA175.5 Power Supply

Part #: AA175.5 In Stock: Ready to Ship Contact for Availability Stock: Select Options for Details
$110.00
AA175.5
pdf_1_name:
Spec Sheet
pdf_1_url:
pdfs/ESTeem-AA175_5.pdf
hide_matrix:
True
in_stock:
True
sales_description:
ESTeem PoE+ Power Supply, 56 VDC/100-250 VAC, IEEE 802.3at, 30W
parent_sku:
AA175.5
facet_accessories:
PoE Injector
facet_accessories:
Power Supply
Adding… The item has been added
Commonly Purchased with:
ESTeem AA166 Surge Protector
$170.00
ESTeem Horizon900 Ethernet / Serial Radio
$2,899.00

Details

ESTeem PoE+ Power Supply, 56 VDC/100-250 VAC, IEEE 802.3at, 30W

Features & Benefits

  • Compliant with IEEE802.3at Standard
  • Gigabit Compatible
  • Level VI Efficiency
  • Full Protection Over Voltage/Current, Short Circuit
  • 6 Foot "€œIEC320 w/ground C14 (US) AC Power Cable Included
  • Very Low Leakage
  • Non-Vented Case

Specifications

  • Input Voltage: 90 to 264 VAC
  • AC Input Frequency: 47 to 63 Hz
  • AC Input Current: 0.8 A (RMS) @ 120VAC
  • Output Voltage: 56 VDC
  • Output Power: 30 W
  • Ripple: 560mV p-p
  • Protection: Foldback Overcurrent/Short Circuit
  • IEEE 802.3af (Mode A) load detection logic
  • Size: 5.51 in.(140mm) L x 2.55 in.(65mm) W x 1.42 in. H (36mm)
  • Shipping Weight: 225g (0.44lb.)
  • Operating Temperature: 0 to +40 degrees C.
  • Relative Humidity: 20% to 90% non-condensing
  • Cooling: Convection - non vented case
  • EMC: FCC Part 15 Class B, EN55022 Class B
  • cUL/UL & CE Safety Approvals

Documentation

Spec Sheet
