Models
| Product ID | Description | Price | |
|---|---|---|---|
| X2 pro 4 | Beijer Electronics X2 pro 4 Graphic, resistive touch, aluminum, panel mount, operator terminal. 480x282 pixels (16:9), LED backlit 4.3" TFT-LCD color display, 300 cd/m² industrial dimmable, 1 GHz single Cortex-A9 CPU, 512 MB RAM, 2 GB MLC NAND flash, 1x Ethernet, 1x3 serial ports, 1x USB 2.0, 1x SD, 24 VDC power supply, -10 to 60 C operating temperature, IP66, CE, FCC, KCC, NEMA 4x/12, UL Type 4x/12 approvals plus DNV, KR, GL, LR, ABS, CCS marine approvals. Includes iX Runtime. WEC2013 Entry. Beijer-branded. (Beijer Part# 630000105) | $803.00 | |
| X2 pro 7 | Beijer Electronics X2 pro 7 Graphic, resistive touch, aluminum, panel mount, operator terminal. 800x480 pixels (16:9), LED backlit 7" TFT-LCD color display, 350 cd/m² industrial dimmable, 1 GHz single Cortex-A9 CPU, 512 MB RAM, 2 GB MLC NAND flash , 1x Ethernet, 1x3 serial ports, 1x USB 2.0, 1x SD, 24 VDC power supply, -10 to 60 C operating temperature, IP65, CE, FCC, KCC, NEMA 4x/12, UL Type 4x/12 approvals plus DNV, KR, GL, LR, ABS, CCS marine approvals. Includes iX Runtime. WEC2013 Entry. Beijer-branded. (Beijer Part# 630000205) | $1,370.00 | |
| X2 pro 10 | Beijer Electronics X2 pro 10 Graphic, resistive touch, aluminum, panel mount, operator terminal. 1024x600 pixels (16:9), LED backlit 10.1" TFT-LCD color display, 500 cd/m² industrial dimmable, 1 GHz dual Cortex-A9 CPU, 1 GB RAM, 2 GB MLC NAND flash, 2x Ethernet, 1x3 serial ports, 2x USB 2.0, 1x SD, 24 VDC power supply, -10 to 60 C operating temperature, IP65, CE, FCC, KCC, NEMA 4x/12, UL Type 4x/12 approvals plus DNV, KR, GL, LR, ABS, CCS marine approvals. Includes iX Runtime. WEC2013 Professional. Beijer-branded. (P/N: 630000305) | $2,120.00 | |
| X2 pro 12 | Beijer Electronics X2 pro 12 Graphic, resistive touch, aluminum, panel mount, operator terminal. 1280x800 pixels (16:9), LED backlit 12.1" TFT-LCD color display, 400 cd/m² industrial dimmable, 1 GHz dual Cortex-A9 CPU, 1 GB RAM, 2 GB MLC NAND flash, 2x Ethernet, 1x3 serial ports, 2x USB 2.0, 1x SD, 24 VDC power supply, -10 to 60 C operating temperature, IP65, CE, FCC, KCC, NEMA 4x/12, UL Type 4x/12 approvals plus DNV, KR, GL, LR, ABS, CCS marine approvals. Includes iX Runtime. WEC2013 Professional. Beijer-branded. (Beijer Part# 640000205) | $3,180.00 | |
| X2 pro 15 | Beijer Electronics X2 pro 15 Graphic, resistive touch, aluminum, panel mount, operator terminal. 1280x800 pixels (16:9), LED backlit 15.4" TFT-LCD color display, 450 cd/m² industrial dimmable, 1 GHz dual Cortex-A9 CPU, 1 GB RAM, 2 GB MLC NAND flash, 2x Ethernet, 1x3 serial ports, 2x USB 2.0, 1x SD, 24 VDC power supply, -10 to 60 C operating temperature, IP65, CE, FCC, KCC, NEMA 4x/12, UL Type 4x/12 approvals plus DNV, KR, GL, LR, ABS, CCS marine approvals. Includes iX Runtime. WEC2013 Professional. Beijer-branded. Beijer PN 640000305 | $4,060.00 | |
| X2 pro 21 | Beijer Electronics X2 pro 21 Graphic, resistive touch, aluminum, panel mount, operator terminal. 1920x1080 pixels (16:9), LED backlit 21.5" TFT-LCD color display, 250 cd/m² industrial dimmable, 1 GHz quad Cortex-A9 CPU, 1 GB RAM, 2 GB MLC NAND flash, 2x Ethernet, 1x3 serial ports, 2x USB 2.0, 1x SD, 24 VDC power supply, 0 to 50 C operating temperature, IP65, CE, FCC, UL approvals. (P/N: 640009505) | $5,300.00 | |
Details
Beijer Electronics X2 pro Series HMI with iX runtime, TFT-LCD touch screen, 1.5 GB application memory, -10 deg. C to +60 deg. C operating temperature. CE, FCC, KCC, UL approvals. DNV, KR, GL, LR, ABS, CCS marine approvals. (Please Specify Model.)
X2 pro High performance HMIs for all automation needs
X2 pro includes a range of high performance industrial panels designed for demanding applications. All with the high performance of powerful ARM Cortex-A9 processors, the latest screen technology and a wide range of connectivity options to cover all your automation needs.
X2 pro panels are available in 4, 7, 10, 12, 15 and 21 inches.
Features & Benefits
- Wide screen format X2 panels offer wide screen format, designed to succeed the traditional 4:3 square aspect ratio.
- UL, CE, FCC and KCC certificates* The entire X2 range offers a strong standard certification with UL, CE, FCC and KCC certificates.
- iX software "€œ why you"„¢ll love our hardware The iX software gives you smart communication tools. iX combines top-class vector graphics and easyto- use functions that provide reliable operation, and almost limitless connectivity to your other equipment.
- Fast forward engineering with WARP Create integrated HMI, control, drives and data communication solutions with WARP Engineering Studio. WARP automatically configures all hardware, software and communication in your application.
- Custom design or non-branded Profile your brand or go for neutral. X2 panels offer custom designed or non-branded front foils, as alternatives to the standard Beijer Electronics branded versions.
- Powerful ARM Cortex-A9 processor Powerful single or dual core ARM Cortex-A9 processor delivers fast screen changes and program execution in demanding applications.
- Robust aluminum housing Robust aluminum housing with IP65, NEMA 4X/12 and UL Type 4X/12 front. Resistant to direct rain, snow or wash-downs, dirt, grime and dust.
- Wide operating temperature -10 deg. C to +60 deg. C* The wide -10 deg. C to +60 deg. C operating temperature range satisfies the demands of most industries.
- Marine certifications* The X2 panels meet extended classes of marine certifications not normally carried by HMIs, making them suitable for all onboard locations.
- CiX CAN, Profibus and MPI module It"„¢s easy to interface with controllers using optional CiX CAN, Profibus or MPI modules.
- SD memory card Card holder and USB connection are located behind the lid on the back of the panel for smart memory expansion, project backup and application loading.
