Models
Product ID | Description | Price | |
---|---|---|---|
X2 marine 7 | Beijer Electronics X2 marine 7 Graphic, resistive touch, aluminum, panel mount,operator terminal. 800x480 pixels (16:9), LED backlit 7" TFT-LCD color display, 500 cd/m² marine dimmable, 1 GHz single Cortex-A9 CPU, 512 MB RAM, 2 GB MLC NAND flash, 1x Ethernet, 1x3 serial ports, 1x USB 2.0, 1x SD, 24 VDC power supply, -15 to 55 C operating temperature, IP65, CE, FCC, KCC, NEMA 4x/12, UL Type 4x/12 approvals plus DNV, KR, GL, LR, ABS, CCS, EN60945 marine approvals. Includes iX Runtime. WEC2013 Entry. Black, Beijer-branded front. (Beijer Part# 630002505) | $1,630.00 | |
X2 marine 7 HB | Beijer Electronics X2 marine 7 HB Graphic, resistive touch, aluminum, panel mount operator terminal. 800x480 pixels (16:9), LED backlit 7" TFT-LCD color display, 1000 cd/m² marine dimmable, 1 GHz quad ARM Cortex-A9 CPU, 2 GB RAM, 2 GB MLC NAND flash, 2x Ethernet, 1x3 serial ports, 2x USB 2.0, 1x SD, 2xDO solid state relay (0.5A), 24 VDC power supply, -15 to 55 C operating temperature, IP65, CE, FCC, KCC, NEMA 4x/12, UL Type 4x/12 approvals plus DNV, KR, GL, LR, ABS, CCS, EN60945 marine approvals. Includes iX Runtime. WEC2013 Professional. Black, non-branded front. (Beijer Part# 630008705) | $2,390.00 | |
X2 marine 7 SC | Beijer Electronics X2 marine 7 SC Graphic, resistive touch, aluminum, panel mount, operator terminal. 800x480 pixels (16:9), LED backlit 7" TFT-LCD color display, 500 cd/m² marine dimmable, 1 GHz quad ARM Cortex-A9 CPU, 2 GB RAM, 2 GB MLC NAND flash, 2x Ethernet, 1x3 serial ports, 1x USB 2.0, 1xSD, 2xDO solid state relay (0.5A), 24 VDC power supply, -15 to 55 C operating temperature, IP65, CE, FCC, KCC, NEMA 4x/12, UL Type 4x/12 approvals plus DNV, KR, GL, LR, ABS, CCS, EN60945 marine approvals. Includes iX Runtime, Codesys runtime EtherCAT/ModbusTCP & RTU. WEC2013 Entry. Black, Beijer-branded front. (Beijer Part# 630008605) | $2,000.00 | |
X2 marine 7 HB SC | Beijer Electronics X2 marine 7 HB SC Graphic, resistive touch, aluminum, panel mount, operator terminal. 800x480 pixels (16:9), LED backlit 7" TFT-LCD color display, 1000 cd/m² marine dimmable, 1 GHz quad ARM Cortex-A9 CPU, 2 GB RAM, 2 GB MLC NAND flash, 2x Ethernet, 1x3 serial ports, 2x USB 2.0, 1xSD, 2xDO solid state relay (0.5A), 24 VDC power supply, -15 to 55 C operating temperature, IP65, CE, FCC, KCC, NEMA 4x/12, UL Type 4x/12 approvals plus DNV, KR, GL, LR, ABS, CCS, EN60945 marine approvals. Includes iX Runtime, Codesys runtime EtherCAT/ModbusTCP & RTU. WEC2013 Professional. Black, non-branded front. (Beijer Part# 630008805) | $2,810.00 | |
X2 marine 15 | Beijer Electronics X2 marine 15 Graphic, resistive touch, aluminum, panel mount, operator terminal. 1280x800 pixels (16:9), LED backlit 15.4" TFT-LCD color display, 450 cd/m² marine dimmable, 1 GHz quad ARM Cortex-A9 CPU, 2 GB RAM, 2 GB MLC NAND flash, 2x Ethernet, 1x3 serial ports, 2x USB 2.0, 1x SD, 24 VDC power supply, -15 to 55 C operating temperature, IP65, CE, FCC, KCC, NEMA 4x/12, UL Type 4x/12 approvals plus DNV, KR, GL, LR, ABS, CCS, EN60945 marine approvals. Includes iX Runtime. WEC2013 Professional. Black, Beijer-branded front. (Beijer Part# 640003305) | $4,310.00 | |
X2 marine 15 HB | Beijer Electronics X2 marine 15 HB Graphic, resistive touch, aluminum, panel mount, operator terminal. 1280x800 pixels (16:9), LED backlit 15.4" TFT-LCD color display, 1000 cd/m² marine dimmable, 1 GHz quad ARM Cortex-A9 CPU, 2 GB RAM, 2 GB MLC NAND flash, 2x Ethernet, 1x3 serial ports, 2x USB 2.0, 1x SD, 2xDO solid state relay (0.5A), 24 VDC power supply, -15 to 55 C operating temperature, IP65, CE, FCC, KCC, NEMA 4x/12, UL Type 4x/12 approvals plus DNV, KR, GL, LR, ABS, CCS, EN60945 marine approved. Includes iX Runtime. WEC2013 Professional. Black, non-branded front. (Beijer Pt #640003505) | $5,110.00 | |
X2 marine 15 SC | Beijer Electronics X2 marine 15 SC Graphic, resistive touch, aluminum, panel mount, operator terminal. 1280x800 pixels (16:9), LED backlit 15.4" TFT-LCD color display, 450 cd/m² marine dimmable, 1 GHz quad ARM Cortex-A9 CPU, 2 GB RAM, 2 GB MLC NAND flash, 2x Ethernet, 1x3 serial ports, 1x USB 2.0, 1xSD, 2xDO solid state relay (0.5A), 24 VDC power supply, -15 to 55 C operating temperature, IP65, CE, FCC, KCC, NEMA 4x/12, UL Type 4x/12 approvals plus DNV, KR, GL, LR, ABS, CCS, EN60945 marine approvals. Includes iX Runtime, Codesys runtime EtherCAT/ModbusTCP & RTU. WEC2013 Professional. Black, Beijer-branded front. (Beijer Part# 640009005) | $4,700.00 | |
X2 marine 15 HB SC | Beijer Electronics X2 marine 15 SC HB Graphic, resistive touch, aluminum, panel mount, operator terminal. 1280x800 pixels (16:9), LED backlit 15.4" TFT-LCD color display, 1000 cd/m² marine dimmable, 1 GHz quad ARM Cortex-A9 CPU, 2 GB RAM, 2 GB MLC NAND flash, 2x Ethernet, 1x3 serial ports, 2x USB 2.0, 1xSD, 2xDO solid state relay (0.5A), 24 VDC power supply, -15 to 55 C operating temperature, IP65, CE, FCC, KCC, NEMA 4x/12, UL Type 4x/12 approvals plus DNV, KR, GL, LR, ABS, CCS, EN60945 marine approvals. Includes iX Runtime, Codesys runtime EtherCAT/ModbusTCP & RTU. WEC2013 Professional. Black, non-branded front. (Beijer Part# 640009405) | $5,490.00 |
Details
Beijer Electronics X2 marine Series HMI with iX runtime, 1.5 GB application memory. E, FCC, KCC, UL approvals. DNV, KR, GL, LR, ABS, CCS marine approvals. (Please Specify Model.)
X2 marine Built for life at sea
X2 marine offers user-friendly, reliable operation offshore, on ships and in other maritime applications. With black frame and nautical society certifications, X2 marine panels are suitable for mounting on the bridge, in the engine room and inside cabins. X2 marine panels are available with optional high brightness display and integrated CODESYS PLC functionality.
X2 marine panels are available in 7 and 15 inches with optional high brightness display and integrated CODESYS PLC functionality.
Features & Benefits
- Wide screen format X2 panels offer wide screen format, designed to succeed the traditional 4:3 square aspect ratio.
- UL, CE, FCC and KCC certificates The entire X2 range offers a strong standard certification with UL, CE, FCC and KCC certificates.
- iX software "€œ why you"„¢ll love our hardware The iX software gives you smart communication tools. iX combines top-class vector graphics and easyto- use functions that provide reliable operation, and almost limitless connectivity to your other equipment.
- Fast forward engineering with WARP Create integrated HMI, control, drives and data communication solutions with WARP Engineering Studio. WARP automatically configures all hardware, software and communication in your application.
- Custom design or non-branded Profile your brand or go for neutral. X2 panels offer custom designed or non-branded front foils, as alternatives to the standard Beijer Electronics branded versions.
- Powerful ARM Cortex-A9 processor Powerful single, dual or quad core ARM Cortex-A9 processor delivers fast screen changes and program execution in demanding applications.
- Robust aluminum housing with IP65, NEMA 4X/12 and UL Type 4X/12 front. Resistant to direct rain, snow or wash-downs, dirt, grime and dust.
- Wide operating temperature -10 deg. C to +60 deg. C The wide -10 deg. to +60 deg. C operating temperature range satisfies the demands of most industries.
- Marine certifications The X2 panels meet extended classes of marine certifications not normally carried by HMIs, making them suitable for all onboard locations.
- CiX CAN, Profibus and MPI module It"„¢s easy to interface with controllers using optional CiX CAN, Profibus or MPI modules.
- SD memory card Card holder and USB connection are located behind the lid on the back of the panel for smart memory expansion, project backup and application loading.
- Dimmable backlight Comfortable and safe operation in high and low ambient light. Backlight is continuously dimmable to less than one cd/m2.
- High brightness display Optional 1,000 cd/m2 backlight provides excellent readability in high ambient light levels such as sunlight.
- Add control by CODESYS Choose optional IEC 61131-3 PLC functionality by CODESYS, running on dedicated CPU cores for safe and fast program execution. Just add remote I/Os for a scalable, cost-effective solution.
- Built-in digital outputs X2 marine panels with high brightness option have built-in digital outputs for direct connection of alarms, signal lights, etc.
- Internal isolation conforms to marine standards for both burst and surge immunity.
