Models
| Product ID | Description | Price | |
|---|---|---|---|
| UC-8210-T-LX-S | Moxa UC-8200 Series Arm-Based Industrial Edge Computer, Armv7 Cortex-A7 Dual-Core 1 GHz Processor, Moxa Industrial Linux Pre-Installed, TPM v2.0, 2 x 10/100Base-TX Ethernet Ports, 2 x RS-232/422/485 Serial Ports, 1 x CAN 2.0 A/B Port, 4 x DI / 4 x DO, 1 x Micro-SD Socket, 12-48 VDC Powered, DIN-Rail Mount, C1D2 & ATEX Zone 2 Rated, -40 to +85 deg C. QTC - Moxa Quick Turn Computer Eligible. | $648.60 | |
| UC-8220-T-LX | Moxa UC-8200 Series Arm-Based Industrial Edge Computer, Wi-Fi Capable (Wi-Fi Package Sold Separately), Armv7 Cortex-A7 Dual-Core 1 GHz Processor, Moxa Industrial Linux Pre-Installed, 2 x 10/100Base-TX Ethernet Ports, 2 x RS-232/422/485 Serial Ports, 1 x CAN 2.0 A/B Port, 4 x DI / 4 x DO, 1 x Micro-SD Socket, 12-48 VDC Powered, DIN-Rail Mount, C1D2 & ATEX Zone 2 Rated, -40 to +70 deg C. | $764.86 | |
| UC-8220-T-LX-US-S | Moxa UC-8200 Series Arm-Based Industrial Edge Computer With Cellular LTE CAT-4 Module (For Verizon & AT&T), Wi-Fi Capable (Wi-Fi Package Sold Separately), Armv7 Cortex-A7 Dual-Core 1 GHz Processor, Moxa Industrial Linux Pre-Installed, TPM v2.0, 2 x 10/100Base-TX Ethernet Ports, 2 x RS-232/422/485 Serial Ports, 1 x CAN 2.0 A/B Port, 4 x DI / 4 x DO, 1 x Micro-SD Socket, 12-48 VDC Powered, DIN-Rail Mount, C1D2 & ATEX Zone 2 Rated, -40 to +70 deg C. Requires 4FF SIM Not Included. QTC - Moxa Quick Turn Computer Eligible. | $1,036.42 | |
Details
Moxa UC-8200 Series Arm-Based Wireless-Enabled DIN-Rail High Performance Industrial Computer with 2 x Serial Ports, 2 x LAN Ports, and 1 x CAN Port. (Please Specify Model.)
The UC-8200 computing platform is designed for embedded data acquisition applications. The computer comes with dual RS-232/422/485 serial ports, dual 10/100/1000 Mbps Ethernet ports, and one CAN port as well as dual Mini PCIe socket to support Wi-Fi/cellular modules. These versatile capabilities let users efficiently adapt the UC-8200 to a variety of complex communications solutions.
The UC-8200 is built around a Cortex-A7 dual core processor that has been optimized for use in energy monitoring systems, but is widely applicable to a variety of industrial solutions. With flexible interfacing options, this tiny embedded computer is a reliable and secure gateway for data acquisition and processing at field sites as well as a useful communications platform for many other large-scale deployments.
Wide temperature LTE-enabled models are available for extended temperature applications. All units are thoroughly tested in a testing chamber, guaranteeing that the LTE-enabled computing platforms are suitable for wide-temperature applications.
Features & Benefits
- Armv7 Cortex-A7 dual-core 1 GHz
- Moxa Industrial Linux with 10-year superior long-term support
- 2 auto-sensing 10/100/1000 Mbps Ethernet ports
- Integrated LTE Cat. 4 module with US/EU/APAC band support
- Dual-SIM slots
- 4 DI & 4 DO
- 1 CAN port supports CAN 2.0A/B
- microSD socket for storage expansion
- Programmable LEDs and a programmable button for easy installation and maintenance
- -40 to 85 deg. C wide temperature range and -40 to 70°C with LTE enabled
