UB20.241 UPS Controller

PULS

UB20.241 UPS Controller

Part #: UB20.241 In Stock: Ready to Ship Contact for Availability Stock: Select Options for Details
$738.00
UB20.241
pdf_1_name:
Spec Sheet
pdf_1_url:
pdfs/ub20e241.pdf
hide_matrix:
True
in_stock:
True
sales_description:
Puls Dimension DC-UPS Controller with Comprehensive Diagnostic and Monitoring Functions, 24VDC/20A Output, 24VDC Input, (2) x External Battery Required 3.9-150Ah, Signaling Terminals.
parent_sku:
UB20.241
facet_input_voltage:
100-240VAC
facet_mounting:
DIN-Rail
facet_output_voltage:
24VDC
facet_type:
UPS
Adding… The item has been added
Commonly Purchased with:
DINSpace BRKT-19DR-4U Rackmount DIN-Rail Adapter
$236.00
PULS CP20.241 Power Supply
$504.00

Details

Puls Dimension DC-UPS Controller with Comprehensive Diagnostic and Monitoring Functions, 24VDC/20A Output, 24VDC Input, (2) x External Battery Required 3.9-150Ah, Signaling Terminals.

The UB20.241 uninterruptible power supply controller (DC-UPS) is used in addition with a 24V power supply and batteries to bridge power failures or voltage fluctuations. This configuration can prevent expensive downtimes, long restart cycles and loss of data.

A unique feature of the UB20 series is the constant voltage in battery mode, which will not change as the batteries discharge. The buffer voltage in battery mode can be set to four different output values. Another feature is the utilization of two independent battery chargers for the two 12V-batteries in series. This feature makes matching batteries unnecessary and allows for precise battery charging, testing and optimized usage of the battery capacity to achieve the longest battery service life.

The UB20.241 includes many battery diagnostic functions that ensure a reliable operation of the entire system. Furthermore, a temperature controlled charging extends the life of the batteries. It also includes a selectable buffer time limiter as well as ready, buffering and replace battery contacts. For safety and maintenance, an inhibit input signal is included which prevents a battery backup.

Features & Specifications

  • No Change in Output Voltage in Battery Mode
  • Selectable Output Voltages in Battery Mode
  • 1-Battery-Concept Each 12V Battery is Charged and Monitored Separately for Longest Battery Life
  • Precise Battery Charging by Using a Temperature Sensor
  • Battery Size Selector for Small or Large Batteries
  • 50% BonusPower®, 30A for up to 4s
  • High Breaking Capacity for Branch Protectors
  • Smart Battery Diagnostics and Monitoring Functions

Documentation

Spec Sheet
