TT420F Temp Sensor

Electro Sensors TT420F temp sensor, flat surface mount. Mounts onto any flat surface with a #10 machine screw (included). 10 FT Cable.

TT420 temperature sensors combine a sensor, signal conditioner and 2-wire loop-powered 4-20 mA transmitter into a rugged and compact package. All models are compatible with standard 2-wire 4-20 mA current loops and analog inputs and are identical with the exception of the measurement probes and fittings.

Features & Benefits

• 2-wire, loop-powered 4-20 mA analog output
• Attachment probe, sensor, 2-wire 4-20 mA
signal conditioner, and cable in one
• No user calibration: works right out of the box
• UL Listed, Intrinsically Safe (IS)
• Class I, Div I (C, D) Class II, Div I (E, F, G)
