MOVE Speed Dome Cameras

MOBOTIX MOVE Speed Dome SD-330 Series Cameras, Weatherproof 3MP Network Camera, Motor-Controlled, Fine-Mechanical Tilting and Panning, IP66, IK10, Temperature range: -40 to 55 deg. C. (Please Specify Model.)

MOBOTIX MOVE Speed Dome Cameras

The MOBOTIX SD-330 and SD-340-IR Speed Dome cameras feature fine mechanical, very quickly reacting swivel and tilt technology, with optical zoom allowing even far-off objects to be recorded, servo feedback technology and an electronic image stabilizer (EIS). The servo feedback technology ensures that the PTZ camera immediately returns to the default target monitoring area if external forces (such as vandalism or environmental vibrations) suddenly exert an influence. The EIS technology can effectively generate stable images by actively recording the targeted motion of the images and compensating for this accordingly; this is particularly helpful when a high zoom level is set and the camera is installed in a place at which the environmental movements (such as from strong wind or trucks driving past) are not always constant.

Features & Benefits

• All systems (P/T/Z/IP) are remote-upgradable
• Servo Feedback
• Wide Dynamic Range (WDR) 120 dB
• Electronic Image Stabilizer (EIS)
• H.264/H.265/MJPEG simultaneous Streaming
• 3MP Resolution
• Zoom Lens:
  • SD-340-IR - 40x Zoom Lens
  • SD-330 - 30x Zoom Lens
• Triple power support (PoE+/DC12 V/AC24 V)
• IP66 Rated
• IK10 Rated
  • SD-340-IR - IK10 Rated Housing Only
  • SD-330 - Full IK10

Stable Image Quality In Every Situation
MOBOTIX MOVE SpeedDome cameras deliver clear images no matter how the camera is moving by actively recording the targeted motion and compensating for this accordingly in real time. The servo feedback technology also ensures that the camera immediately and automatically returns to its previous position if external forces (such as deliberate changes or strong gusts of wind) or environmental vibrations have moved it.

Remotely Adjustable Focal Length
MOBOTIX MOVE cameras have an electronic Vario lens that is adjustable remotely via the camera€™s firmware and which focuses automatically when the focal length is changed. The viewing angle and field of view can be flexibly adjusted using the focal length. MOBOTIX MOVE SpeedDome cameras can be set or changed to any horizontal field of view between 2° (telephoto) and 62° (wide) at any time.

Wide Dynamic Range
The MOBOTIX MOVE cameras feature integrated, high-quality WDR image processing technology. This allows the cameras to automatically compensate for particularly strong differences in brightness in the recorded scene independently through differing exposure times, and thereby avoid generating over- or underexposed areas in images.

Wide Dynamic Range shows more frame details for applications with highly demanding light conditions, such as in the entryways of buildings, in store display windows and at loading bays or drive-in entrances to parking lots etc. (Combination of very light and dark areas.).
