IW9165E-B-WGB Rugged Access Point

Cisco Catalyst IW9165E-x-WGB Rugged Wireless 9165E Access Point, 11ax 6E, 4 RF Ports, B Domain, WGB Software.

Cisco Catalyst IW9165E Rugged Access Point and Wireless Client

The Catalyst IW9165E is designed to add ultra-reliable wireless connectivity to moving vehicles and machines. Its compact form factor makes it very simple to integrate into industrial assets. It can operate in WGB or Cisco URWB mode to enable any use case and leverage the existing wireless environment.

The Catalyst IW9165E supports Cisco WGB mode, which allows it to connect to a Cisco access point infrastructure, and Universal WGB (uWGB) mode, which allows it to connect to a third-party access point infrastructure. Both of these modes help bridge the wired clients that are behind the WGB to the access point on the infrastructure side.

Low power consumption, rugged IP30 design, small form factor, and DIN rail mount capabilities make the Catalyst IW9165E an ideal product operating as a wireless client for automated guided vehicle (AGV) and Autonomous Mobile Robot (AMR) deployments. An M12 adapter and rail certifications make the Catalyst IW9165E a preferred choice for onboard train deployments as well.

Secure infrastructure
Trustworthy systems built with Cisco Trust Anchor technologies provide a highly secure foundation for Cisco products. With the Catalyst IW9165 Series, these technologies help assure hardware and software authenticity for supply chain trust and strong defense against man-in-the-middle attacks that compromise software and firmware. Trust Anchor capabilities include:

• Image signing
• Secure Boot
• Cisco Trust Anchor module

Features and Benefits

• Workgroup bridge (WGB) software​
• ​​​​Dual 802.11ax radios (5GHz, 5/6GHz)
• ​​Two RJ45 ports (2.5, 1Gbps), optional M12 adapter​
• ​​Rugged design supporting temperature ranges of -20 to 50 deg. C
• EN50155-certified to support shock and vibration
