GP-IN2680 Dual Sharkee series 4x4 MiMo 4G/5G Antenna

Panorama Antennas, GP-IN2680, 7-in-1 Dual Sharkee Antenna (4 x 4 MIMO 4G/5G LTE plus 2 x 2 MIMO Wi-Fi plus GPS/GNSS), 617-7125 MHz, Panel/Threaded Bolt Mount, SMA-Male and RP-SMA-Male Connectors, 5 Meter Cable, Black.

GPS[X]D4[X]-6-60 | Dual Sharkee® | 4x4 MiMo 4G/5G Sharkfin Antenna

The GPS[X]D4[X]-6-60[-X] is an advanced 4G/5G, GPS/GNSS and WiFi antenna with a sharkfin style housing. The housing contains a 4x4 MiMo antenna function for 4G/5G (617-960/1427-6000MHz), up to 6x6 MiMo dual-band WiFi, which supports WiFi 6e. It can include up to 4x active antennas for GPS/GLONASS/Galileo/BeiDou each with 26dB gain LNA and advanced filtering for LTE Band13/14 operation.

In addition, there is an integral stud mount for an external antenna whip. A blanking cap is supplied for when this whip position is not required.

The antenna should be installed on a metal panel when a comms whip is used, but if a whip is not required, then it may be fitted on a non-metallic panel and still offer similar performance.

The shark fin design provides multiple antenna functions while remaining discreet and is suitable for public safety (overt/covert), industrial and transport applications where a cost-effective, efficient and robust antenna is essential. Requiring only a single hole mounting, the antenna reduces vehicle damage, installation time, cost and visual impact whilst protecting a vehicle's resale value.

Features and Benefits

• Distinctive Automotive SharkFin design
• Up to a 15-in-1 Combination Antenna Solution
• Covers all 4G/5G LTE bands, WiFi 6e and GPS/GNSS bands
• 4x4 MiMo 600-6000MHz LTE antenna elements
• Offers up to 6x6 MiMo WiFi 6e, and up to 4x GPS/GNSS
• Allows for external VHF, UHF or combination whip for voice radio connectivity
