AWK-4131-M12-US-T Ethernet Radio

Moxa IEEE802.11a/b/g/n IP68 Wireless AP/Bridge/Client, M12 Connector, -40 to 75°C.

Special sales item with limited quantities available. If you are interested in ordering multiple items, please contact us to verify inventory.

Moxa's AWK-4131 is a 3-in-1 industrial wireless AP/bridge/client that meets the growing need for faster data transmission speeds and wider coverage by supporting IEEE 802.11n technology with a net data rate of up to 300 Mbps. The AWK-4131 combines two adjacent 20 MHz channels into a single 40 MHz channel to deliver a potent combination of greater reliability and more bandwidth.

With a dust-tight/weatherproof IP68-rated design, the AWK-4131 allows you to extend existing wired networks to outdoor locations. The AWK-4131 can operate on either the 2.4 or 5 GHz bands and is backwards-compatible with existing 802.11a/b/g deployments to future-proof your wireless investments.

Features and Benefits

• IEEE 802.11a/b/g/n compliant
• One M12/SFP Gigabit combo port
• Up to 300 Mbps data rate
• Supports 100 ms Turbo Roaming
• MIMO technology increases data throughput and range
• Rugged IP68-rated housing

Higher Data Rate and Greater Bandwidth

• High-speed wireless connectivity with up to 150 Mbps data throughput
• MIMO technology to improve the capacity of multiple data stream transmits and receives
• Increased channel width with channel bonding technology

Industrial and Outdoor Features for Critical Environments

• Industrial-grade QoS and VLAN for efficient data traffic management
• IP68-rated metal housing
• PoE and dual DC power inputs
