UB40.241 UPS Controller
Product ID
UB40.241
Availability
DESCRIPTIONPuls Dimension DC-UPS Controller with Comprehensive Diagnostic and Monitoring Functions, 24VDC/40A Output, 24VDC Input, (2) x External Battery Required 3.9-150Ah, Signaling Terminals. The UB40.241 is an uninterruptible power supply controller (DC-UPS controller), which is used in combination with a 24V power supply and an external 24V-battery pack to bridge power failures. When the power supply provides sufficient voltages, the DC-UPS controller charges the battery. When the power supply voltage fails, the energy stored in the battery is released to the DC bus in a regulated process. A unique feature is the battery charger, which can balance two unmatched batteries and which includes two independent battery testers for the two 12V batteries connected in series. This feature makes matching batteries unnecessary and allows for precise battery charging, testing and optimized usage of the battery capacity to achieve the longest battery service life. The device includes various battery diagnostic functions including a battery-low pre-warning signal that ensure a reliable operation of the entire system. Furthermore, temperature-controlled charging extends the life of the batteries. It also includes a selectable buffer time limiter as well as “Ready”, “Buffering” and “Replace battery” contacts. For safety and maintenance, an inhibit-input signal is included to enable phases without enforced buffering. Features & Specifications- 1-Battery-Concept - Each 12V battery is charged and monitored separately for longest battery life, matching of batteries not necessary
- Output is decoupled from the input to separate load circuits into
buffered and non-buffered sections - Allows VRLA Battery sizes between 12Ah and 200Ah; “Battery Size” selector for various battery sizes
- 50% BonusPower for up to 5s
- Superior battery management for longest battery life
- Comprehensive diagnostic and monitoring functions
- “Replace Battery” signal included
- “Battery-Low Prewarning” signal included
- Selectable buffer time limiter
- Temperature controlled battery charging
