ML60.241 Power Supply
Product ID ML60.241
Availability
DESCRIPTIONPuls Compact MiniLine Single Phase Power Supply, 60W, 24VDC/2.5A Output, 100/240VAC Input, DIN-Rail Mount Plastic Housing, -10 deg. to +70 deg. C, Class 1, Div. 2 Rated. A compact size, light weight, simple mounting onto the DIN-rail and the utilization of only quality components are what makes the MiniLine power supplies so easy to use and install within seconds. A rugged electrical and mechanical design as well as a high immunity against electrical disturbances on the mains provides reliable output power. This offers superior protection for equipment which is connected to the public mains network or is exposed to a critical industrial environment. The MiniLine series offers output voltages from 5 to 56Vdc and a power rating from 15W to 100W. The supplementary MiniLine decoupling diode module MLY02.100 allows building of redundant systems or to protect against back-feeding voltages. Features & Benefits - 100-240V Wide Range Input
- NEC Class 2 Compliant
- Adjustable Output Voltage
- Efficiency up to 89.7%
- Low No-load Losses and Excellent Partial-load Efficiency
- Compact Design, Width only 45mm
- Full Power between -10°C and +60°C
- Large International Approval Package
- 3-Year Manufacturer's Warranty
